Flat Roof Skylight Installation Guide Video - Step by Step
[/vc_column_text][vc_video link="https://youtu.be/NDKB5RrF5_w" el_width="90" align="center" image_poster_switch="no"][vc_column_text woodmart_inline="no" text_larger="no"]
Pitched Roof Skylight Installation Guide Video - Step by Step
[/vc_column_text][vc_video link="https://youtu.be/FvTY1-UvTh0" el_width="90" align="center" image_poster_switch="no"][vc_column_text woodmart_inline="no" text_larger="no"]
Lantern Roof Skylight Installation Guide Video - Step by Step
[/vc_column_text][vc_video link="https://www.youtube.com/watch?v=MK06uvuTqxs" el_width="90" align="center" image_poster_switch="no"][woodmart_title style="simple" woodmart_css_id="62bb6fde03358" responsive_spacing="eyJwYXJhbV90eXBlIjoid29vZG1hcnRfcmVzcG9uc2l2ZV9zcGFjaW5nIiwic2VsZWN0b3JfaWQiOiI2MmJiNmZkZTAzMzU4Iiwic2hvcnRjb2RlIjoid29vZG1hcnRfdGl0bGUiLCJkYXRhIjp7InRhYmxldCI6e30sIm1vYmlsZSI6e319fQ==" title="Structural opening – provided By builder" after_title="Bear in mind our Skylights sizes are the sizes of the bottom (internal) glass panel. The top panel is stepped by 100mm on each side, and the overall externally visible size is 200mm bigger in both directions:
For example, only in this guide will we present installation sketches for a Skylight 600mm x 600 mm. For all other sizes, we provide installation sketches in the gallery of each size separately.
DOUBLE/TRIPLE GLAZED SKYLIGHT 600x600mm has the following sizes:"][vc_single_image image="8446" img_size="full" alignment="center" parallax_scroll="no" woodmart_inline="no"][woodmart_text_block woodmart_css_id="62bb712ef3b7a" woodmart_inline="no" responsive_spacing="eyJwYXJhbV90eXBlIjoid29vZG1hcnRfcmVzcG9uc2l2ZV9zcGFjaW5nIiwic2VsZWN0b3JfaWQiOiI2MmJiNzEyZWYzYjdhIiwic2hvcnRjb2RlIjoid29vZG1hcnRfdGV4dF9ibG9jayIsImRhdGEiOnsidGFibGV0Ijp7fSwibW9iaWxlIjp7fX19" parallax_scroll="no" wd_hide_on_desktop="no" wd_hide_on_tablet="no" wd_hide_on_mobile="no"]
The upstand should protrude a minimum of 150mm above the roof level.
A minimum pitch of 6 degrees relative to the horizon must be provided to avoid water pooling in the middle of the glass panel (for every meter of Skylight a 10cm fall is required). It is worth spending a few extra minutes before applying the silicone to run a water test to ensure the water is not pooling (even though you are installing glass it will still bend in the middle)
Upstand opening should allow for 5mm tolerance on each side:
[/woodmart_text_block][vc_single_image image="8447" img_size="full" alignment="center" parallax_scroll="no" woodmart_inline="no"][woodmart_text_block woodmart_css_id="62bb71627425b" woodmart_inline="no" responsive_spacing="eyJwYXJhbV90eXBlIjoid29vZG1hcnRfcmVzcG9uc2l2ZV9zcGFjaW5nIiwic2VsZWN0b3JfaWQiOiI2MmJiNzE2Mjc0MjViIiwic2hvcnRjb2RlIjoid29vZG1hcnRfdGV4dF9ibG9jayIsImRhdGEiOnsidGFibGV0Ijp7fSwibW9iaWxlIjp7fX19" parallax_scroll="no" wd_hide_on_desktop="no" wd_hide_on_tablet="no" wd_hide_on_mobile="no"]
The internal distance upstand to upstand needs to be 10mm bigger than the quoted skylight size (in our example: 610mm by 610mm)
Skylight Support – provided By builder
The Skylight support is a 25x50mm (2”x1”) timber:
[/woodmart_text_block][vc_single_image image="8448" img_size="full" alignment="center" parallax_scroll="no" woodmart_inline="no"][woodmart_text_block woodmart_css_id="63c7d5618e6ef" woodmart_inline="no" responsive_spacing="eyJwYXJhbV90eXBlIjoid29vZG1hcnRfcmVzcG9uc2l2ZV9zcGFjaW5nIiwic2VsZWN0b3JfaWQiOiI2M2M3ZDU2MThlNmVmIiwic2hvcnRjb2RlIjoid29vZG1hcnRfdGV4dF9ibG9jayIsImRhdGEiOnsidGFibGV0Ijp7fSwibW9iaWxlIjp7fX19" parallax_scroll="no" wd_hide_on_desktop="no" wd_hide_on_tablet="no" wd_hide_on_mobile="no"]
Install the support in such a way that the top of support is as follows:
-Triple Glazed Skylight – 48mm below the top of upstand
Weather the upstand
Apply the roof covering material to cover the external face and top of the upstand:
[/woodmart_text_block][vc_single_image image="8449" img_size="full" alignment="center" parallax_scroll="no" woodmart_inline="no"][woodmart_text_block woodmart_css_id="62fd2b5b8cfb7" woodmart_inline="no" responsive_spacing="eyJwYXJhbV90eXBlIjoid29vZG1hcnRfcmVzcG9uc2l2ZV9zcGFjaW5nIiwic2VsZWN0b3JfaWQiOiI2MmZkMmI1YjhjZmI3Iiwic2hvcnRjb2RlIjoid29vZG1hcnRfdGV4dF9ibG9jayIsImRhdGEiOnsidGFibGV0Ijp7fSwibW9iaWxlIjp7fX19" parallax_scroll="no" wd_hide_on_desktop="no" wd_hide_on_tablet="no" wd_hide_on_mobile="no"]
Once you finish weathering the upstand, you are ready to install the Skylight.
Make sure all surfaces where the silicone will be applied are clean of dirt, dust, moisture, etc.
1.Apply the foam rope on top of the 2”x1” timber support to level off any discrepancies which will prevent any pressure and stop cracking on the bottom glass laminated pane. THE WARRANTY WILL BE VOID IF A FOAM ROPE IS NOT USED.
2.Apply, generously, on top of the upstand weatherproof sealant, usually, 1 tube is enough for 6 linear meters.
3.Lower the skylight with suction cups, and make sure you check the load on each cup.
4.Apply waterproof sealant on the underside of the overhang and smooth it over once more to make sure it is watertight.
For a pitched roof please follow the technical diagram below:
[/woodmart_text_block][vc_single_image image="8451" img_size="full" alignment="center" parallax_scroll="no" woodmart_inline="no"][woodmart_text_block woodmart_css_id="62bb73888c3be" woodmart_inline="no" responsive_spacing="eyJwYXJhbV90eXBlIjoid29vZG1hcnRfcmVzcG9uc2l2ZV9zcGFjaW5nIiwic2VsZWN0b3JfaWQiOiI2MmJiNzM4ODhjM2JlIiwic2hvcnRjb2RlIjoid29vZG1hcnRfdGV4dF9ibG9jayIsImRhdGEiOnsidGFibGV0Ijp7fSwibW9iaWxlIjp7fX19" parallax_scroll="no" wd_hide_on_desktop="no" wd_hide_on_tablet="no" wd_hide_on_mobile="no"]
* With regards to the silicones we recommend the following products:
- Black weather silicone – DOWSIL 791 Weatherproofing Sealant
DO NOT USE ACRYLIC SEALANTS!
Be careful what silicones you are using to install and weather tight your Skylight. We recommend the above products as fully compatible with our glazing unit silicones.
A chemical incompatibility between silicones used in manufacturing the glazing unit and installing it can lead to discoloration and/or loss of adhesion to the substrate. This means possible depressurization of the glazing unit (allowing moisture to penetrate inside the glazing unit and internal condense), not sufficient bonding to the support structure, and poor weather tightness (possible leaks).
[/woodmart_text_block][/vc_column][/vc_row][vc_row][vc_column][vc_column_text woodmart_inline="no" text_larger="no"]
THE WARRANTY WILL BE VOID IF A FOAM ROPE IS NOT USED AND NOT PURCHASED FROM US.[/vc_column_text][/vc_column][/vc_row]
